Product Description Features: 1.The module uses L298N chip as the main drive, with driving ability, low heat, anti-jamming features. 2.It can be used to take power through the built-in 78M05 drive power part of the work, but in order to avoid damage to the regulator chip, when a drive voltage greater than 12V, please use an external 5V logic supply. 3. Uses high-capacity filter capacitors, freewheeling diode protection, reliability can be improved. Note: Available only on Mekatroniks store In Pakistan, Cheap and Best Quality products Store. 1. When you drive voltage (the figure identified as 12V input, can accept the actual input range is 7-12V) to 7V -12V, You can enable the on-board 5V logic supply, when using the onboard 5V power supply, interface 5V ，Do not enter the power supply voltage, but can lead to 5V voltage for external use. (This is the routine use!) 2. When the drive voltage higher than 12V,equal to less than 24V (chip can support manual proposes to 35V, but in accordance with an 298 Conservative general inspection applications to 24V maximum voltage support has been very great! Time),such as to drive the rated voltage 18V motor. First, you must unplug the onboard 5V output enable jumper caps. And then 5V 5V output port External Access L298N internal voltage logic circuitry. (This is a high-voltage driver unconventional application)
