Description Thank you for visiting our product page! We strive to provide you with an effortless shopping experience. Our checkout process is simple and offers various shipping options with tracking. Furthermore, we believe in maximizing the value of your purchase. On this website, you can find detailed instructions on how to use this product and explore various projects we have created using it. These resources are designed to help you make the most of your purchase. How to use this product — Click on me Free projects and tutorials — Click on me If you have any questions or encounter any issues, our dedicated customer support team is always ready to assist you. Please don’t hesitate to reach out to us through our user-friendly Contact Us page. We are committed to ensuring your complete satisfaction. Lastly, we highly value your feedback. Once you have experienced our product, we would greatly appreciate it if you could leave a review. Your opinion matters to us! Thank you for considering our product. We look forward to serving you. Product details 1.44 Inch With PCB backplane Dot matrix: 128X128! Driver: ST7735 Only 4 IOs can drive 1.8 Inch 1.8-inch SPI serial screen with backplane module requires at least 4 IO drivers Size: 1.8-inch SPI serial bus Resolution: 128*160 Driver IC: ST7735 The features of this module Support Arduino various MCUs in-line without any wiring Integrated voltage regulator IC, support 5V or 3.3V power supply Onboard level shifting scheme, truly compatible with 5V/3.3V IO level. Support a variety of microcontroller IO connections Integrated SD card expansion circuit, Reserve SPI FLASH font circuit to facilitate extended application 2.0 Inch 2.0-inch SPI serial screen with backplane module, at least 4 IO drivers Size: 2.0-inch SPI serial bus Resolution: 176*220 Driver IC: ILI9225 The features of this module Support Arduino various MCUs in-line without any wiring Integrated voltage regulator IC, support 5V or 3.3V power supply Onboard level shifting scheme, truly compatible with 5V/3.3V IO level. Support a variety of microcontroller IO connections Integrated backlight control circuit, can control on-off or PWM dimming, Integrated SD card expansion circuit, Reserve SPI FLASH font circuit to facilitate extended application Pin Description 11Pin LCD module interface pin definition: Vcc: module power supply positive, can input 5V or 3.3V GND: Module power supply negative, ground GND: The module power supply is negative, grounded, or can be left floating. NC: Hanging NC: Hanging LED: backlight control pin, connected to high level CLK: Serial SPI clock signal SDI: serial spi data input signal RS: Command (RS = 0) parameter (RS 1) selection RST: LCD reset signal CS: liquid crystal chip selection signal 4 Pin Expansion Pin Interface Pin Definition: SD CS: SD card selection signal SD_ MOSI: SPI bus MOSI data input SD_ MISO: SPI bus MISO data output SD_ SCK: SPI bus serial clock signal 2.2 Inch Only 5 IO ports (analog SPI) direct hardware SPI input voltage support 5V/3.3V ILI9341 driver resolution 240*320 2.4 Inch At least 4 IO drivers are required without touch, with a minimum of 9 IO drivers with touch. Resolution 240*320 2.8 Inch At least 4 IO drivers are required without touch, with a minimum of 9 IO drivers with touch Resolution 240*320
